Installing a Media Converter Module
52
Table 3 lists the connector types and maximum distances for the
AT-PB13 and AT-PB14 media converter modules.
Table 3 AT-PB13 and AT-PB14 Maximum Operating Distances
Status LEDs
Table 4 list the status LEDs.
Table 4 AT-PB10 Series Status LEDs
Model
10Base-FL Port 10Base-T Port
Connector
Maximum
Distance
Connector
Maximum
Distance
AT-PB13 ST 2 km (1.2 mi) RJ-45 100 m (328 ft)
AT-PB14 SC 2 km (1.2 mi) RJ-45 100 m (328 ft)
LED Color Description
All Models
PR Green Power is applied to the media converter.
LK Green A link has been established on the port.
RX Green Data is being received.
ML Green
OFF
The MissingLink feature is enabled on the media
converter.
The MissingLink feature is disabled and the media
converter is performing a link test.
AT-PB15 Only
TX Green Data is being transmitted on the BNC port.
RX Green Data is being received on the BNC port.
ONLINE Green The BNC port is connected to an active 10Base2
segment.
COL Green The BNC port is sensing a collision signal.
