Installing a Media Converter Module
72
Table 26 lists the port specifications for the AT-PB1000 Series modules.
Table 26 Fiber Optic Port Specifications
Model Cable
Transmitter
Output Power
(average)
Wavelength
Minimum
Receiver
Sensitivity
(average)
1000Base-SX Port
All Models 50/125 or 62.5/125 µm
multimode -9.5 to -4.0 dBm 850 nm -17.0 dBm
1000Base-LX Port
AT-PB1001 10/125 µm single-mode -9.5 to -3.0 dBm 1310 nm -20.0 dBm
50/125 or 62.5/125 µm
multimode -11.5 to -3.0 dBm 1310 nm -20.0 dBm
AT-PB1001/2 10/125 µm single-mode -3.0 to 0.0 dBm 1310 nm -24.0 dBm
AT-PB1001/3
1
10/125 µm single-mode -5.0 to 0.0 dBm 1550 nm -24.0 dBm
AT-PB1001/4
1
10/125 µm single-mode 0.0 to 5.0 dBm 1550 nm -24.0 dBm
1. For maximum performance of Gigabit Optical Datalinks when greater than 40 km (24.8 mi) and operating within the 1550 nm optical spectrum, it is mandatory that the Single
Mode Fiber (SMF) be rated as “non-dispersion-shifted,” “dispersion shifted,” or “non-zero dispersion shifted.”
