Installing a Media Converter Module
70
Table 23 lists the connector types and maximum distances for the
AT-PB1000 Series Gigabit Media Converter modules.
Table 23 AT-PB1000 Series Maximum Cabling Distances
Status LEDs
Table 24 lists the status LEDs.
Table 24 AT-PB1000 Series Status LEDs
Model
1000Base-LX 1000Base-SX
Connector
Maximum
Distance
1
1. Assumes 10/125 micron single-mode fiber optic cable.
Connector
Maximum
Distance
2
2. Assumes 50/125 micron multimode fiber optic cable.
AT-PB1001/1 SC 10 km
(6.2 mi) SC 550 m
(1,804 ft)
AT-PB1001/2 SC 25 km
(15.5 mi) SC 550 m
(1,804 ft)
AT-PB1001/3 SC 40 km
(24.8 mi) SC 550 m
(1,804 ft)
AT-PB1001/4 SC 70 km
(43.4 mi) SC 550 m
(1,804 ft)
LED Color Description
PR Green Power is applied to the media converter.
ML Green
OFF
The MissingLink feature is enabled.
The MissingLink feature is disabled and the media
converter is performing a link test.
LK Green A link has been established on the port.
