PowerBlade PBC18 Installation Guide
59
Table 10 lists the cable specifications for the 100Base-FL fiber optic port
for all AT-PB100 Series Media Converters when operating in full-duplex
mode.
Table 10 100Base-FX Fiber Optic Port Specifications (Full-duplex)
Model Cable
Maximum
Distance
1
1. Maximum distance for 100 Mbps Optical Datalinks is dependent on the following factors: type of optical fiber, duplex mode of
both end-nodes, and maximum optical loss budget for each of the optical fibers at the operating optical wavelength.
Maximum
Allowable Loss
Budget
AT-PB101 50/125 or
62.5/125 µm
multimode 2 km (1.2 mi) 13 dB at 1310 nm
AT-PB102 50/125 or
62.5/125 µm
multimode 2 km (1.2 mi) 13 dB at 1310 nm
AT-PB103/1 9/125 µm
single-mode 15 km (9.3 mi) 16 dB at 1310 nm
AT-PB103/2 9/125 µm
single-mode 40 km (24.8 mi) 30 dB at 1310 nm
AT-PB103/3 9/125 µm
single-mode 75 km (46.5 mi) 33 dB at 1310 nm
AT-PB103/4 9/125 µm
single-mode
2
2. The cable must be non-dispersion-shifted, dispersion-shifted, or non-zero dispersion-shifted single-mode fiber optic cable.
100 km (62 mi) 34 dB at 1550 nm
