Operating and Managing the FORMULA 8200 Switch
4-14
Displaying Virtual Port Information
To display virtual port information about a transparent
bridge port:
Use the VLAN/SHOW/VPORT command.
The screen shows a 16-port FORMULA 8200 ( Physical
Port ID ) and their VLAN assignments ( VLAN ID ) with
spanning tree status ( Bridge State ). Ports that are linked
and operational as shown as active ( Operation Status ),
and VLAN is enabled on all ports ( Admin Status ).
The system automatically creates Virtual Port ID 17 and its
corresponding Virtual Physical Port ID 33 for VLAN 1 routing
functions. As you create additional VLANs and enable routing
for them (Chapter 3, Configuring a Virtual LAN (VLAN) on
page 3-8), the system creates additional Virtual Port IDs but
assigns the same Physical Port ID number, 33, for the routing
function.
/VLAN/SHOW/VPORT
Virtual Port Information :
Virtual
Port ID
======= Physical
Port ID
======== VLAN
ID
==== Port
Type
====== Port
MAC Address
================ Bridge
State
======= Admin
Status
======= Operation
Status
=======
1 1 10 BRIDGE 0:60:e8:ff:ff:20 FORWARD ENABLE ACTIVE
2 2 10 BRIDGE 0:60:e8:ff:ff:21 FORWARD ENABLE ACTIVE
3 3 2 BRIDGE 0:60:e8:ff:ff:22 FORWARD ENABLE ACTIVE
4 4 2 BRIDGE 0:60:e8:ff:ff:23 DISABLE ENABLE INACTIVE
5 5 10 BRIDGE 0:60:e8:ff:ff:24 FORWARD ENABLE ACTIVE
6 6 10 BRIDGE 0:60:e8:ff:ff:25 FORWARD ENABLE ACTIVE
7 7 10 BRIDGE 0:60:e8:ff:ff:26 FORWARD ENABLE ACTIVE
8 8 10 BRIDGE 0:60:e8:ff:ff:27 FORWARD ENABLE ACTIVE
9 9 9 BRIDGE 0:60:e8:ff:ff:28 DISABLE ENABLE INACTIVE
10 10 1 BRIDGE 0:60:e8:ff:ff:29 FORWARD ENABLE ACTIVE
11 11 1 BRIDGE 0:60:e8:ff:ff:2a FORWARD ENABLE ACTIVE
12 12 9 BRIDGE 0:60:e8:ff:ff:2b FORWARD ENABLE ACTIVE
13 13 9 BRIDGE 0:60:e8:ff:ff:2c FORWARD ENABLE ACTIVE
14 14 15 BRIDGE 0:60:e8:ff:ff:2d FORWARD ENABLE ACTIVE
15 15 15 BRIDGE 0:60:e8:ff:ff:2e FORWARD ENABLE ACTIVE
16 16 15 BRIDGE 0:60:e8:ff:ff:2f FORWARD ENABLE ACTIVE
17 33 1 ROUTER 0:60:e8:ff:ff:50 ENABLE ACTIVE
