Allied Telesis FORMULA 8200 - Manual (Page 126)

Command Reference
5-48
VBRIDGE/SHOW/BRIDGE Example
To display Spanning Tree bridge parameters:
Use the VBRIDGE/SHOW/BRIDGE command. For
example, to display parameters for VLAN 1, enter the
following command:
VBRIDGE/SHOW > bridge 1
The following display appears:
/VBRIDGE/SHOW/BRIDGE 1
Spanning Tree Parameters for VLAN 1
Spanning Tree Status : ON
Priority : 32768 (0x8000)
Bridge ID : 8000-0060e8ffff00
Designated Root : 8000-0060e8ffff00
Cost to Root Bridge : 0
Root Port : None
Hold Time : 1
Topology Changes : 0
Last Topology Change : No Topology Change So Far
Bridge Aging Timer : 300
----------------------------------------------------------------
Hello Time 2 secs System Hello Time 2 secs
Current Parameters
Parameters System Uses When
Attempting to Become Root:
Max Age 20 secs System Max Age 20 secs
Forward Delay 15 secs System Forward Delay 15 secs
Global parameters
Local parameters
