Connecting the Console
2-2
Connecting the Console
The RS232C console port permits you to connect a terminal or local
workstation for system management. The console terminal interface
is a DB9 (DCE) male connection.
Note
The console is required to confirm that the switch is configured and
operating correctly after installation.
Connect a VT-100 terminal or equivalent to the FORMULA 8200 using
a 9-pin null-modem RS232 serial cable. You can also use a DOS®,
Windows®, or UNIX® workstation running in terminal emulation
mode. The cable connection to the switch must have a female DB9
connector.
Terminal
Configuration
To configure the terminal:
Use the following parameters:
❑ Baud rate: 9600
❑ Data bits: 8
❑ Stop bits: 1
❑ Parity: none
❑ Number of lines per page: 25
Viewing
Terminal
Configuration
Using the CLI
Once you have completed the installation, you can then use the
following command to show the console parameters:
CONSOLE/SHOW - show console parameters
For a complete description and additional information about this
and other commands, see Chapter 5, Command Reference
.
