FORMULA 8200 User’s Guide
5-43
VBRIDGE/SHOW/PORT Example
To display the virtual port parameters of a VLAN for all
linked ports:
Enter the following command:
/VBRIDGE/SHOW/PORT
A similar display appears (VLAN 1 is used as an example):
Table 5-16 defines the fields in the display.
/> VBRIDGE/SHOW/PORT 2
/VBRIDGE>
Port
Number
------
Pri
--- State
--------
Path
Cost
---- Desig
Cost
----- Desig
Port
----- Root
Port
----- Root Bridge ID
Desig Bridge ID
----------------
5 128 FORWDING 10 0 128-5 None 8000-0060e80033e0
8000-0060e80033e0
11 128 FORWDING 10 0 128-11 None 8000-0060e80033e0
8000-0060e80033e0
Table 5-16
VBRIDGE/SHOW/PORT Command Parameters
Parameter Description
Port Number The port number belonging to the VLAN
Pri Part of port ID which is used to determine which port gets blocked or forwarded
Range: 0 to 255
Default setting: 128.
State The current state of the port: disabled, listening, learning, forwarding, or blocking
Path Cost The contribution of the path through this port, when the port is the root port, to the
total cost of the path to the root for this bridge
Desig Cost The cost of the path to the root offered by the designated port on the LAN to which
this port is attached
Desig Port The port identifier of the bridge port identified as the designated port for the LAN
associated with the port
Root Port The port identifier of the port that offers the lowest cost path to the root, i.e., that
port for which the sum of the values of the designated cost and path cost parameters
held for the port is the lowest
Root Bridge ID The Bridge ID of the root.
Designated Bridge
ID The ID of the bridge believed to be the designated bridge for the LAN that is
associated with this port.
