FORMULA 8200 User’s Guide
2-3
Observing the Power-On Self Test
When the FORMULA 8200 is powered on, it automatically runs a
power-on self-test (POST) to verify that all components are
functioning normally.
As POST verifies the basic operation of the switch, it displays a series
of messages on the console. A similar screen display appears:
Boot POST in progress...
PROM version: 1.0.7
Sizing DRAM (value displayed is bank size or error code)...
DRAM now configured into a contiguous block:
Address: ............. 0xa0000000 - 0xa07ffffc
Running DRAM test...
Initializing 4650 icache and dcache...
Initializing PIG chip...
Initializing PMIU chips...
.
.
Boot POST complete, passing control to firmware...
Loading /flash/firmware...Starting at 0x80010000...
Firmware version 1.4.3
Date= 1/26/98 time= 11:34:27
Restore configuration for system
IP address = 0.0.0.0
Number of ports = 16
Configuration changed
srm_init success
Allied Telesyn International
Copyright@ 1997 Allied Telesyn All rights reserved.
Switch Init Success
Login:
Post
begins
Component
tests
Firmware
loads
Vendor
information
System
information
