EN - English - I
nstruc
tions manual
41
It is possible to set 5 different speeds for pan and tilt
and it is also possible to enable advanced functions
using the Action menu (which contains, for example,
the Autopan, Start, Stop commands etc.). If you
want to control the PTZ using the mouse, directly
from the video window, check Mouse PTZ in the
control panel. You can then use the mouse to control
both movements and zoom (Zoom + and - are
situated in the centre).
Mouse PTZ
Fig. 99
To set the configuration parameters of the pan & tilt
by means of OSM, enable the corresponding function
using the control panel.
OSD
Fig. 100
9.7.3.1 Controlling PTZ movements
To set movement control via the control panel or via
mouse, proceed as follows:
Select the Setup / Setup Camera menu and select
the PTZ tab.
Select the first unit, or the one you want to configure,
from the Media Source list. Check the Enable PTZ
box. Then click on Apply. This will automatically set
the Videotec Macro protocol at 38400 baud.
Fig. 97
Repeat the procedure for the other units to be
controlled, directly from the PTZ setup menu (see
illustration above); just select the other units present
in the Media Source list of the Camera Tree menu,
one at a time, and check Enable PTZ, then click on
Apply.
h When the unit settings have been inserted,
quit the NVR programm and re-start it so
that all the changes will be saved.
To control a unit via the control panel, select the unit
to be controlled by clicking with the mouse on the
corresponding video window, and then operate from
the control panel .
Fig. 98
