EZ-Guide Plus Lightbar Guidance System Getting Started Guide Troubleshooting 59
Troubleshooting
Problem Possible cause Solution
Screen is blank or
hard to see Backlight is off Turn on the cab light. Then use Brightness/Contrast to turn
on the backlight.
Backlight level needs to
be adjusted Select Brightness/Contrast screen to change the
brightness.
The lightbar has locked
up Disconnect power, wait 30 seconds, and then reapply
power.
Contrast is wrong Press and hold o as you reapply power. Contrast is reset
to the default value.
No power Make sure that the lightbar is connected to a power source.
I need to reset the
start of the first
swath You have mapped the
start of the first swath at
the wrong time Press u to select the
A
icon and then press o to reset
Point A.
My lightbar LEDs,
buttons, or screen
do not appear to be
working properly There is a fault with the
hardware Run hardware tests. From the Lightbar menu, select Tests.
Run any or all of the tests. If any of the tests fail, contact
your local reseller for information on repairing or replacing
the lightbar.
NO GPS COMMS The lightbar is not
communicating with the
integrated GPS receiver The GPS receiver or lightbar is faulty. Contact your local
reseller for information about repairing or replacing the
faulty item.
The external GPS receiver
is not connected to the
lightbar Connect the external GPS receiver to the data port on the
lightbar. In the Data Port Settings screen, set Input to
External GPS or TSIP Receiver.
To use the integrated GPS receiver, set the Data Port Input
field to None.
NO GPS POSITIONS
message flashes on
screen
The antenna is not
connected to the lightbar Connect the antenna to the lightbar or to the external GPS
receiver. See Installing the system, page 11.
The antenna, antenna
cable, or GPS antenna
connection is faulty From the Configuration menu, select GPS / GPS
Diagnostics. Press
u . If the Antenna option displays None ,
there is a problem with the antenna, antenna cable, or the
GPS antenna connection.
Contact your local reseller for information about repairing or
replacing the faulty item.
