EZ-Guide Plus Lightbar Guidance System Getting Started Guide Overview of the Menu 53
Overview of the Menu
Menu Menu option Description Default value
EZ-Steer Back to Main Menu Return to the main menu —
Axle/Ant Offset Distance between rear axle and antenna 0"
Use/Save Config Loads or saves vehicle configurations —
Vehicle Setup Vehicle type and settings Type – Tractor
Steer whl dia. – 16.0"
Angle/turn – 20°
Freeplay Left – 1.00"
Freeplay Right – 1.00"
Wheel base – 118"
Heading Filter – 3
EZ-Calibration Guided process that configures EZ-Steer
system for your vehicle —
Aggressiveness Aggressiveness percentage 105%
Engage Options Min speed – 2.0mph
Max speed – 15.0mph
Max angle – 15°
Engage Offln. – 6'0"
Diseng. Offln. 10'0"
O’ride Sensitivity – 20%
Motor Spd – Auto High
Engage On AB – Off
Operator Timeout Alert appearance rate 10min
External Switch Whether a switch is connected Disable
Diagnostics EZ-Steer system information 2
Fault history EZ-Steer system faults —
