20 Getting Started EZ-Guide Plus Lightbar Guidance System Getting Started Guide
Status text
The Plan Map, Perspective Map, and Status views display four status text items. The
Plan Map and Perspective Map views show two of the status text items at the top of
the screen, which then change to the other two items. The status text items cycle
every three seconds. The Status screen shows all four items at once.
Status text item Definition
Swath Number Swath number of the closest swath.
Offline Distance Distance offline from the closest swath.
Speed Current speed.
Heading Current heading.
Field Area Area of the field calculated half a swath width outside the path driven. A
value is displayed only for Headland patterns.
Mapped Area The size of a mapped area, in acres (US) or hectares (metric).
Satellites Number of GPS satellites used.
HDOP Horizontal Dilution of Precision. This is a measure of accuracy based on
the geometry of the satellites in the sky. An HDOP of 2 or less is good.
Height Current antenna height above mean sea level (MSL).
GPS Status Current GPS status.
XP/HP status (Convrg./Unconvrg.) (If you use OmniSTAR XP/HP with an
optional high accuracy receiver.)
Correction Age The age of the GPS signal.
Coverage Area Area applied while spray switch was on or sprayed using the EZ-Boom
system. Calculated as distance x swath width. To save the coverage area
value when turning off the system, pause guidance before disconnecting
power.
Nudge Displays accumulated nudge perpendicular to the direction of travel.
Yaw Rate The speed of change in yaw.
Roll Rate The speed of change in roll.
Overlap The current amount of spray overlap (positive value) or skip (negative
value).
TRate Application target rate: Shows which rate is selected (Rate1, Rate2, or
Manual) and the target rate.
Pressure The current spray system pressure.
Pressure B The second pressure sensor.
