EZ-Guide Plus Lightbar Guidance System Getting Started Guide Configuring Guidance Settings 39
Configuring Guidance Settings
You can configure the guidance and warning settings of the EZ-Guide Plus lightbar
guidance system to suit your personal preference and your application.
Guidance settings
Configure the following lightbar settings from the Guidance menu.
LED mode
LED spacing
The LED spacing is the distance represented by one LED. Decrease the LED spacing to
increase the sensitivity of the LEDs.
Look ahead
Use the look ahead time to predict your future vehicle path to allow for reaction time
and vehicle turn speed. Set the look ahead time in seconds. For larger vehicles that
take longer to turn, increase the time.
Note — For 4WD articulated tractors, always set the look ahead time to 0 seconds.
Auto-detect turn
This setting is used only for the Adaptive Curve pattern. This setting defaults to On,
which means that a new swath is automatically generated when a U-turn is detected.
To manually identify the end of each adaptive curve swath, change this setting to Off.
Terrain compensation
For terrain compensation information, refer to the EZ-Steer System Reference Guide.
Mode Definition
Chase Chase the lights to stay online. The lights represent the swath location
relative to the vehicle.
Pull Center the lights to stay online. The lights represent the vehicle
location relative to the swath.
