EZ-Guide Plus Lightbar Guidance System Getting Started Guide Overview of the Menu 57
Warnings Back to Main Menu Returns to main menu —
Headland Warning Turn the headland warning ON or OFF.
Configure the warning lead time. Warning – ON
Lead time – 0s
Offline Warning Distance off-swath at which the offline warning
message appears. Set to zero to disable the
warning. 0' 0"
Low Acc Warning High Acc Only – Accept only high accuracy
positions.
Warn Low Acc – Accept all positions, but warn
when low accuracy.
No Warning – Accept all positions, including
less accurate positions, without warning. Warn Low Acc
Audible Warning Turn the audible warning alarm ON or OFF. OFF
GPS Back to Main Menu Returns to main menu. —
GPS Diagnostics Display GPS receiver status and diagnostic
information. —
DGPS Diagnostics View DGPS satellite diagnostic information. —
GPS Limits Min Satellites
Max HDOP
Min Elevation
1
Min SNR
1
5
3.0
8"
40.0
Corrections
2
Configure receiver correction options.
Filter
2
Configure GPS filter settings. Depends on receiver
Subscription
3
View OmniSTAR VBS or XP/HP subscription
expiry information —
Defaults Back to Main Menu Returns to main menu. —
Restore Defaults Return all configuration settings to factory
defaults. —
About... — Display lightbar version information. GPS Rate – 5Hz NMEA
Pass Code — Enables/disables the configuration protection
pass code. Off
1
These options are only available when you have a lightbar with an integrated receiver, the high accuracy smart
antenna, or the high accuracy box antenna.
2
These options are only available when you have a lightbar with an integrated GPS receiver or are using a TSIP-
capable external receiver with the Data Port Setting Input set to TSIP External.
3
These options are only available on TSIP-capable receivers that support OmniSTAR corrections.
Menu Menu option Description Default value
