EZ-Guide Plus Lightbar Guidance System Getting Started Guide Overview of the Menu 55
Terrain
Comp. Back to Main Menu Return to the main menu. —
Orientation The direction that controller connectors point. Front
Filter Terrain compensation filter Heavy 3
Antenna Height The height of the antenna above the ground. 0"
Calibration Performs the terrain compensation calibration. —
Hide EZ-Steer Hide the EZ-Steer menu No
T2 Tech. On/Off T2 technology on/off On
Diagnostics Terrain compensation information —
Lightbar Back to Main Menu Return to the main menu. —
Display Config Turn on or turn off screen items, such as
progress lines, field boundary, or adjacent
swath lines and configure the view setting. Progress lines – ON
Adjacent swaths – ON
Field boundary – ON
AB Line – ON
View – Auto
Path display – ON
Contrast/Brightness Adjust the screen contrast and backlight
brightness. Adjust the LED brightness.
Screen contrast – 10
Screen backlight – Auto
LED brightness – 20
Ant/Impl. Offset Distance from the antenna to the implement. 0' 0"
Lightbar Mount Upright.
Inverted – Inverts display and offline LEDs. Upright
Status Text Configure the status text items for the map
views and the status screen. Map and 3D View
– Offline Distance
– Swath Number
– Offline Distance
– Swath Number
Status Screen
– Field Area
– Coverage Area
– Speed
– Heading
Menu Menu option Description Default value
