EZ-Guide Plus Lightbar Guidance System Getting Started Guide Getting Started 15
Views
To change between the four views, select
4
.
View Details
Perspective map
This is the default screen for guidance.
It displays two status text options.
Plan map
This is the default screen when you:
•
define the field
• pass the end of the swath
• move offline by more than half a swath
• pause guidance
It displays two status text options.
Status
This screen displays up to four status text options.
To configure the text, use the Status Text configuration
option.
Offline
This screen displays the vehicle offline error for the last 10
seconds. This view is not available until you have defined a
field.
Summary
This screen displays covered area. It allows you to see any
skips or overlaps in material application.
To zoom in on or move the Summary view, select the
5 icon.
