EZ-Guide Plus Lightbar Guidance System Getting Started Guide Getting Started 21
Stopping the status text from cycling
To stop the Status Text from cycling in the Plan Map and Perspective Map views, set
the:
• first and third status items the same
• second and fourth status items the same
Current Rate The current rate (gal/Ac or L/ha).
Current Flow The current flow (gal/min or L/min).
Applied Volume Total volume (gal or L) applied.
Tank Volume The current volume of product in the spray tank (gal or L).
Swath Pts The number of points in the current swath.
Swath Len The length of the current swath.
Conv Dist XP/HP convergence distance.
Roll The roll angle of the vehicle.
Field Num ID# of the AB Line.
None No status text is displayed.
Status text item Definition
