EZ-Guide Plus Lightbar Guidance System Getting Started Guide Getting Guidance 23
Getting Guidance
The EZ-Guide Plus lightbar guidance system provides the following pattern options:
For more information, see Using guidance patterns, page 24 .
Note — If you are using WAAS corrections and the system has been turned off for
more than 2 hours, a warning appears when the first WAAS DGPS position is
received. For best accuracy, wait for 10 minutes after receiving the WAAS DGPS
warning before you set an AB Line or select a stored field.
Note — If you are using a receiver with RTK or OmniSTAR XP/HP corrections, do not
define a new guidance line until the Low Accuracy message stops flashing.
Otherwise, you may get significant pass-to-pass drift until the receiver reaches its
highest level of accuracy (Fixed or Convrg.).
If the GPS Status is Float or Unconvrg.,
the accuracy is still converging.
Pattern Definition
AB Line Straight guidance based on A and B points that define the initial line.
A+ Straight guidance based on an A point and the previous line heading.
Identical curve Curve guidance based on the initial curve.
Adaptive curve Curve guidance based on the last curve driven.
Headland Records headlands of any shape as you drive around the field. Can
provide guidance on multiple headland passes and straight swath
guidance inside the headlands.
Center-pivot Curve guidance in a center-pivot field.
Row finder When you drive with an implement that spans several rows, the system
guides you to the next appropriate swath without having to count the rows
in between yourself.
Area Mark out an area to show obstacles/excluded areas, calculate the size of
an area, or to display an area onscreen.
Select Stored AB Select and load a previous AB Line.
Delete Current AB Delete the current AB Line.
Delete all ABs Delete all saved AB Lines
