34 Getting Guidance EZ-Guide Plus Lightbar Guidance System Getting Started Guide
Each nudge moves the guidance line by the Nudge Increment value. For example, if
the Nudge Increment is set to 0' 3" and you press
3
twice, the total nudge distance
is 6 inches to the right.
To display the total accumulated nudge perpendicular to the current vehicle heading,
select Nudge as one of the status text items. See Status text, page 20.
To reset the nudge distance to 0, select Guidance / Reset Nudge, and then select
Reset. The main screen appears, with the swath in the original position.
Pause and resume
To pause guidance, select
2
or press p on the remote
control.
When you pause guidance:
• The display changes to the Plan map view (if the
Display Config / View option is set to Auto)
• An icon appears at the pause location and indicates
the direction of pause
• The pause swath appears on the screen
• The screen automatically zooms to keep your current position and the pause icon
on the screen. You cannot zoom manually.
• A dotted line joins your current position and the pause point
• The map status text changes to display the distance to the pause point and the
offline distance from the pause swath
• The LEDs do not provide offline guidance while you are more than half a swath
from the pause swath
• Progress lines and adjacent swaths are not displayed
To resume guidance, select
2
or press p on the remote control
Driving on large fields
At distances greater than 10 km (6.2 mi) from the original AB Line, the curvature of
the Earth’s surface can cause a reduction in GPS position accuracy. Consequently, the
lightbar does not support more than 1000 swaths to the left and 1000 swaths to the
right of the original AB Line.
If you need to create more than 1000 swaths either to the left or the right of the AB
Line, create a second AB Line. This will ensure that you maintain the highest level of
steering accuracy.
