Page 753

Page 22-38
information tell us is that somewhere between
φ
= 58
o
and
φ
= 59
o
, the shear
stress,
τ’
xy
, becomes zero.
To find the actual value of
φ
n, press $. Then type the list corresponding to
the values {
σx σy τxy}, for this case, it will be
{ 25 75 50 } [ENTER]
Then, press
@CC&r. The last result in the output, 58.2825255885
o
, is the actual
value of
φ
n.
A program to calculate principal stresses
The procedure followed above to calculate
φ
n, can be programmed as follows:
Program PRNST:
«
Start program PRNST (PRiNcipal STresses)
INDAT
Enter data as in program MOHRCIRC
CC&r
Calculate
σc, r, and fn, as in MOHRCIRC
“
φ
n” TAG
Tag angle for principal stresses
3 ROLLD
Move tagged angle to level 3
R C DUP
Convert
σc and r to (σc, r), duplicate
C R + “
σPx” TAG
Calculate principal stress
σPx, tag it
SWAP C R - “
σPy” TAG
Swap,calculate stress
σPy, tag it.
»
End program PRNST
To run the program use:
J
@PRNST
Start program PRNST
25˜
Enter
σx = 25
75˜
Enter
σy = 75
50`
Enter
τxy = 50, and finish data entry.
The result is:
Ordering the variables in the sub-directory
Running the program MOHRCIRCL for the first time produced a couple of new
variables, PPAR and EQ. These are the Plot PARameter and EQuation variables
