3–Viewing Router Information
iSCSI Ports
3-30 ISR654602-00 H
Base Name Examples:
Before enabling the embedded symbolic name option:
iqn.2004-08.com.qlogic:isr6200.0823e00014.b1.02.50001fe150069
d2d
After enabling embed symbolic name option (with the symbolic name set to
oxygen):
iqn.2004-08.com.qlogic:isr6200.0823e00014.b1:oxygen.02.50001f
e150069d29
 Link Status identifies the port connection status: Link Up or Link Down.
 MAC Address assigned to the port; this parameter cannot be changed.
 Actual Port Speed indicates the real speed, for example, 1Gbps/FDX. If the
port's configuration or connection has changed, the value may not be
current. Click the Refresh button to view the current speed.
 Programmed Port Speed indicates the configured data rate for the port. To
change the data rate, select one of the following data rates:
 Auto is the data rate determined by network attachment.
 100 Mbps specifies 100 megabits per second.
 1 Gbps specifies 1 gigabit per second.
 10 Gbps specifies 10 gigabits per second.
 Link Rate Mode is available If you selected a specific Programmed Port
Speed (not Auto). Select either Auto, Half Duplex, or Full Duplex mode.
 Flow Control. If you selected a specific Programmed Port Speed (not
Auto), you can enable or disable flow control.
iSCSI Port Network Settings
The iSCSI Port Network Settings area provides the following parameters:
 Port Status allows you to enable or disable the port when the port link is up.
 IPv4 Address. When using an IPv4 address, define the following
parameters:
 IP Address is the IP address to which the port responds. An
un-initialized port has an IP address of all zeros.
 Subnet Mask is the subnet mask used by the port.
 Gateway is the gateway for the selected port.
