3–Viewing Router Information
FC Ports
3-22 ISR654602-00 H
 Remote Peer Usage Type indicates the peer router’s license usage type
that was selected on the Add Remote Peer Wizard. The usage type is one of
the following:
 Data Migration indicates that the peer is licensed to migrate data
between local and remote LUNs.
 Remote Maps indicates that the peer is licensed to connect two
individual SANs.
 Remote IP Connection Address x specifies the IP address of the local and
remote iSCSI ports used for the remote peer connection. If multiple
connections exist between the blades, they are listed in order.
 Click Logout to remove the remote peer connection.
 Click Add Connection to create a second connection between the peer
routers. A maximum of two connections can be established between the
peer routers.
FC Ports
When you click a Fibre Channel port in the router tree, information for that port
appears in the right pane.
The FC port view includes the following pages:
 “Information” on page 3-28
 “Advanced Configuration” on page 3-24
 “Statistics” on page 3-25
 “Performance” on page 3-27
