3–Viewing Router Information
Host Entities
ISR654602-00 H 3-71
 LUN State indicates whether the LUN is online or offline.
 Free/Total Metadata Extents indicates the available and total resources on
the data management LUN.
 Free/Total Data Extents indicates the available and total resources on the
data management LUN.
Host Entities
A host entity is a logical construct consisting of zero or more initiator ports for one
or more protocols. The host entity simplifies the configuration process and
prevents configuration errors during LUN masking by:
 Representing a single server with one or many Fibre Channel, iSCSI, or
FCoE ports.
 Representing one or many servers, each with one or many Fibre Channel,
iSCSI, or FCoE ports. Servers are used in a cluster environment where the
same LUNs must be presented to multiple servers and cluster hosts.
 Being available across the blades of a chassis.
Selecting the Host Entities branch on the router tree does not provide any
information in the right pane. Select a specific host entity node in the router tree to
view the <Host_Name> page in the right pane.
> Page
The <Host_Name> page lists information for the selected host entity, as shown in
Figure 3-42 .
