3–Viewing Router Information
Router Blades

3-18

ISR654602-00 H

SNMP Configuration

The SNMP Configuration options include the following:

System OID indicates the vendor’s system object identifier.

System Description shows the product description of the router (QLogic
iSR6200).

SNMP Settings include the following:

Read Community: Type a password that authorizes an SNMP
management server to read information from the router. This is a
write-only box. The value on the router and the SNMP management
server must be the same. The read community password can be up to
32 characters excluding the number sign (#), semicolon (;), and

comma (,). The default is public.

Trap Community: Type a password that authorizes an SNMP
management server to receive traps. This is a write-only box. The
value on the router and the SNMP management server must be the
same. The trap community password can be up to 32 characters
excluding the number sign (#), semicolon (;), and comma (,). The

default is private.

System Location specifies the name of the router location. The name
can be up to 64 characters excluding the number sign (#), semicolon

(;), and comma (,).

System Contact specifies the name of the person to be contacted to
respond to trap events. The name can be up to 64 characters
excluding the number sign (#), semicolon (;), and comma (,).

Authentication Traps enables or disables the generation of traps in
response to authentication failures.

Enabled SNMP Trap Receivers

Select the Enabled SNMP Trap Receivers check box to enable the trap receiver
boxes and specify each IP address, trap port, and trap version. The router can
support up to eight trap addresses. For each entry, specify the following:

IP Protocol: Select the IP protocol version from the list, either IPv6
Address
or IPv4 Address. The corresponding IP Address box changes to
accept the appropriate format.

IP Address specifies the IP address to which the SNMP traps are sent.

Trap Port identifies the port number on which the trap is sent. The default is
162.

Trap Version specifies the SNMP version (1 or 2) with which to format traps.
