A–Simple Network Management Protocol
SNMP Trap Configuration
ISR654602-00 H A-3
SNMP Trap Configuration
SNMP trap configuration lets you set up to eight trap destinations. Choose from
Trap 1–Trap 8 to configure each trap.
Table A-2 describes the parameters for
configuring an SNMP trap.
Management Information Base (MIB)
This section describes the QLogic management information base (MIB). The MIB
includes the following tables:
 “Network Port Table” on page A-3
 “FC Port Table” on page A-6
 “Initiator Object Table” on page A-9
 “LUN Table” on page A-11
 “VP Group Table” on page A-13
 “Sensor Table” on page A-15
Network Port Table
The network port table contains a list of network ports that are operational on the
router. The entries in this table include the management port (labeled MGMT),
and the gigabit Ethernet ports (labeled GE1 and GE2). For details, see the
iSR6200 QLogic intelligent Storage Router (iSR) Installation Guide.
Table A-2. SNMP Trap Configuration Parameters
Parameter Description
Trap n enabled Enables or disables trap n. If disabled, the trap is not configured.
Trap address * Specifies the IP address to which the SNMP traps are sent. A maximum of eight
trap addresses are supported. The default address for traps is
0.0.0.0 .
Trap port a
a Trap address (other than 0.0.0.0 .) and trap port combinations must be unique. For example, if trap 1 and trap 2
have the same address, they must have different port values. Similarly, if trap 1 and trap 2 have the same port value,
they must have different addresses.
Port number on which the trap is sent. The default is 162 . If the trap destination
is not enabled, this value is 0 (zero). Most SNMP managers and management
software listen on this port for SNMP traps.
Trap version Specifies the SNMP version ( 1 or 2 ) with which to format traps.
