To set a static main
route
1. Click the Setup tab to display the Setup menu.
2. Click Host Settings in the left menu to expand the Host Settings menu.
3. Click Routing: Main to display Host Settings - Routing: Main page.
Figure 2-11. Host Settings - Routing: Main Page
4. Use the controls to complete the configuration, as described in the following table.
5. Click Save to write your settings to memory or click Reset to return the settings to
their previous values.
Setting Static In-
Path Routes
You configure static, in-path network routes if your network configuration requires
additional static in-path network routing rules in the Host Settings - Routing: In-Path
page.
The values you specify set the routing table for in-path interfaces (as opposed to the
primary interface).
Control
Description
Add New Route
Destination. Type the IP address in the text box.
Netmask. Type the subnet mask in the text box.
Gateway. Type the IP address for the gateway in the text box. The gateway must be in the
same network as the primary or auxiliary interface.
Add Route. Click this button to add the entry to the list.
Remove Selected Routes. To remove a route, click the check box next to the entry and
click Remove Selected Routes.
