Viewing the
Current
Connection
Details Report
The Current Connections: Connection Details report displays details about the
connected HP EFS WAN Accelerator such as the source and destination IP address, the
peer HP EFS WAN Accelerator, the inner local port, and so forth. The Current
Connections report contains the following table that summarizes current connection
details.
What This Report
Tells You
The Current Connections Detail report answers the following questions:
How is the status of this system?
What is the peer for this system?
What are the total number of bytes in and out of this system?
What is the percent reduction of traffic for this system?
Field
Description
Type
Specifies the type of connection.
Source
Specifies the source IP address for the connection.
Destination
Specifies the destination IP address for the connection.
Peer Appliance
Specifies the IP address of the remote HP EFS WAN
Accelerator the connection is going through.
Inner Local Port
Specifies the local port for the inner connection to the peer
HP EFS WAN Accelerator.
Outer Local
Specifies the local port for the outer connection to the client
or server.
Outer Remote
Specifies the remote port for the outer connection to the
client or server.
Client-Side
Specifies whether the connection is a client-side HP EFS
WAN Accelerator for this connection.
Since
Specifies the time the system has been active.
App
Specifies the internal protocol blade that is used to service
the connection.
Bytes In (LAN)
Specifies the total number of LAN bytes for this connection.
Bytes Out (WAN)
Specifies the total number of WAN bytes for this connection.
Reduction
Specifies the percent reduction of traffic over the WAN.
