HP StorageWorks Enterprise File Services WAN Accelerator User Manual
Page 125
HP S
TORAGE
W
ORKS
EFS WAN A
CCELERATOR
M
ANAGEMENT
C
ONSOLE
U
SER
G
UIDE
125
3
C
REA
T
IN
G
HP
EF
S W
A
N
A
CC
ELE
RAT
OR
R
EP
OR
T
S
AND
To create a Bandwidth
Optimization report
1. Click the Reports tab to display the Performance - Bandwidth Optimization page.
Figure 3-1. Performance - Bandwidth Optimization Page
2. Use the controls to customize the report, as described in the following table.
Control
Description
Period
Select Last Hour, Last Day, Last Week, or Last Month from the Period drop-down
list.
Application
Select FTP, HTTP, CIFS:NetBIOS, CIFS:TCP, or MAPI from the drop-down list. The
default value is All.
Direction
Select Bi-directional, WAN-to-LAN, or LAN-to-WAN from the drop-down list.
Appliances
The default is to include all appliances. To set a custom group, click All and use the
dialog box to select an appliance, a group, or a custom selection of appliances to include
in the report.
Refresh
Set a rate to refresh the report display:
• To refresh your report every 15 seconds, click 15s.
• To refresh your report every 30 seconds, click 30s.
• To turn off refresh, click off.
Note: The refresh rate does not affect polling. Polling occurs every 5 minutes.
Printer icon
To print your report, click the Printer icon in the upper right corner of the page.
