2 Hardware Installation and Configuration
19
Attach "NetServer" end of cable here
HP Remote
Assistant Board
Attach "Remote
Assistant" end
of cable here
Tape clamp under
chassis here
Figure 2-7. Installing the Cable in an HP NetServer LF or LH
Attach "NetServer"
end of cable here
HP Remote
Assistant Board
Attach "Remote
Assistant" end
of cable here
Tape clamp to
chassis here
Figure 2-8. Installing the Cable in an HP NetServer LX
