155
H LED Codes
These tables list the error codes which will be flashed on the LED to indicate problems
with the HP Remote Assistant EISA Board. (Only the first failure found will be
reported.)
Each failure is stored as a 4 BCD digit code. Only the three leading digits will be
flashed. This will allow each code to have up to 10 "sub-codes" which can be
presented by the diagnostic utility. To get detailed error codes, run the DOS-based
diagnostic utility on the HP Remote Assistant Server Disk, by typing:
A:\HPRADIAG\POSTREP.EXE.
LED codes are flashed in the following sequence:
1. OFF for several seconds.
2. One long ON pulse.
3. Three sets of short ON pulses indicating the error codes.
4. Repeat 1 through 3 indefinitely.
For example, a 1-3-2 error would appear as: a long OFF, a long ON, flash, pause,
flash-flash-flash, pause, flash-flash.
Processor Failure Codes
PROCESSOR Failure Codes
LED
Code REPORT
codes Failure Name Failure Reason Possible Cause
none
LED off none PROCESSOR NOT
RUNNING Processor fails test of
internal registers and
cannot operate.
Processor halted Defective
Microprocessor
(U40) Defective
oscillator (Y10)
