Service Required
The resource requires service. This condition generates an alarm, and the
component that requires service is colored red in the tree pane and in the
Physical and ServerNet views of the view pane.
Fabric State
Value Meaning
Up
At least one of the processors on the local node can communicate with at least one
processor on one of the remote nodes.
Down
No processor on the local node can communicate with a processor on any remote node.
This value is the default.
Note: The Fabric state for a one-node ServerNet cluster is Down because
communication with processors in remote nodes is not possible.
Configuration Tag
This table shows the supported configuration tags for each topology:
Topology Supported Configuration Tags*
OSM and Guided Procedures
Display Value
N/A 0x11111 (manufacturing default) 0x11111
Star 0x10000 Max 8 nodes, nodes 1-8 (0x10000)
Split-star 0x10000 Max 16 nodes, nodes 1-8 (0x10000)
0x10001
Max 16 nodes, nodes 9-16
(0x10001)
Tri-star 0x10002 Max 24 nodes, nodes 1-8 (0x10002)
0x10003
Max 24 nodes, nodes 9-16
(0x10003)
0x10004
Max 24 nodes, nodes 17-24
(0x10004)
* SCF displays the long form of the configuration tag. For example, configuration tag 0x10000
appears in SCF as 0x00010000.Configuration Version
Port Connectivity Status
Value Valid Only For
Reset
Link dead (Loss of optical signal)
Link dead (Transceiver absent)
No link alive
Link alive, port disabled
