Switch PIC
A card in the 6780 switch that plugs into the switch logic board. Most switch PICs (except for
maintenance PICs and router interconnect PICs) are populated with transceivers that enable
connections to the different nodes, layers, and zones of the cluster.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
PIC
Example: Switch PIC $ZZSMN.Y11.13 (1011.1.13)
See also Router Connections for Router Interconnect PICs .
Attributes
Switch PIC
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or
service is required.
Values
Physical
Type
The type of PIC.
Values: Single-mode fiber-optic, Multimode fiber-optic, Router
Interconnect, Maintenance
Part Number The part number of the switch PIC.
Fault LED State
The state of the fault LED on the switch PIC.
Values: On, Off, On and Blinking, Off and Blinking
Track ID The track ID of the switch PIC.
Hardware Revision The hardware revision of the switch PIC.
Presence Whether the PIC is installed and responding.
Logical
Enabled State
The initial state of the component at the time of discovery.
Enabled: The component is operational.
Disabled: The component is present but not operational.
Device State
Indication of whether the switch has a fault.
Values: OK, Fault
