Attributes
PIF
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Values
Logical
Current Configured Speed The transmission rate for the ServerNet addressable controller.
Duplex Mode
The transmission mode for the ServerNet addressable controller.
Values: Half Duplex, Full Duplex, Unknown
Network MAC Address The media access control (MAC) address of the PIF network.
Maximum Speed
The maximum transmission rate for the ServerNet addressable
controller.
Values: 10 megabits per second, 100 megabits per second, Unknown
Device State
The state of the component as known to the NonStop Kernel operating
system on the server.
Values
Processors with Data Path
The processor numbers for processors that have a successful data path to
the PIF. If no processor has a path, "None" is shown.
Example: (0,1)
Hardware MAC Address The media access control (MAC) address of the PIF hardware.
Ring State
Only for the TRSA CRU.
The current state of the Token Ring.
Values: Opened, Opening, Open Failure, Closed, Closing, Ring Failure
Ring Open Status
Only for the TRSA CRU.
Status (success or reason for failure) of the most recent attempt to enter
the Token Ring.
Values: Last Open Successful, No Open Attempted, Bad Parameter,
Lobe Failed, Signal Loss, Insertion Timeout, Ring Failure, Beaconing,
Duplicate MAC, Request Failed, Remove Received
Actions
Abort
Terminates operation of the PIF. When the Abort action finishes, the PIF is in the Stopped state.
Configure LIF
Configures the associated LIF .
