Group
A group contains all the components that are serviced by a pair of
S7x00, S7x000, and S86000 servers, an enclosure contains one group, and a group contains one
.
Location in OSM Tree: Under System
Example: Group 1
Attributes
Group
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Logical
Service LED State
Indication of whether the service LED is on or off.
On: An OSM user has turned on the service LED by using the Set Service LED
State action.
Off: An OSM user has turned off the service LED by using the Set Service LED
State action.
Turning on the group service LED helps you locate the group for servicing. This
feature is useful when a system consists of multiple enclosures.
Actions
Power Off
Upon initiating the action, it first performs precautionary checks to ensure that you can safely power
off. These checks ensure that:
If the group is an enclosure on the inner tetrahedral ring, there are no enclosures off this
enclosure.
●
There are no IOMF enclosures off this enclosure.
●
If the checks complete successfully, or you choose to disregard any warnings and proceed, the action
allows you to disable the batteries and halt the processors.
After these operations complete successfully (or you choose to disregard any warnings), you can
complete the action and power off the group.
Set Service LED State
