Attributes, Actions – HP NonStop G-Series User Manual
Page 100
Attributes
Disk Collection
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Actions
None.
Fan
A component that circulates air into the enclosure to help maintain optimal temperature. Each system
enclosure contains two fans, and each fan is connected to one processor multifunction (
) CRU.
Location in OSM Tree: System > Group > Module > Fan
Slot Location: Fan CRUs are located in slots 25 and 26 on the appearance side of processor
enclosures.
Note: The fans built into the S7400, S7x000, and S86000 power supplies (slots 31 and 32) are
field-replaceable units (FRUs) and must be serviced only by your service provider.
Example: Fan (1.1.22)
Attributes
Fan
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Physical
Power State Whether the component is powered on.
Logical
Enabled State
The current state of the fan as known to the NonStop Kernel operating system.
Rotations Sensor
Normal Minimum Value
The minimum acceptable fan speed is 1800 RPM. If the speed falls below
1800, an alarm is generated.
