DLC Task State
The state of the data link control (DLC) task associated with the line as known to
the NonStop Kernel operating system.
Values: Started, Stopped, Unknown
Device Name
The name of the WAN device associated with the line.
Example: $TP6S1
If no device is configured, "FREE" is shown.
Actions
External Loopback Test
Performs the external loopback firmware diagnostic test.
Start DLC Task
Starts the data link control (DLC) task associated with the SWAN Line. When the Start action
completes, the task is in the Started State.
Stop DLC Task
Stops the data link control (DLC) task associated with the SWAN Line. When the Start action
completes, the task is in the Stopped State. Device objects already using the task are not affected by
this action, but subsequent attempts to download tasks will fail.
SWAN Path
A subcomponent of SWAN CLIP s and SWAN 2 CLIPs. Every CLIP has two paths, path A and path
B. These paths represent the two Ethernet interfaces on the SWAN concentrator.
Location in OSM Tree: System > SWAN Collection > SWAN > CLIP > Path
Example: PATH $ZZWAN.#SWAN2.1.B
Attributes
PATH $ZZWAN
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Values
Logical
MAC Address The media access control (MAC) address of the SWAN Path.
IP Address The IP address configured for the SWAN Path.
