Replace
Launches a guided procedure, which provides step-by-step instructions for replacing the ServerNet
Switch Board.
Set LED State
Turns the ServerNet Switch Board LED on or off.
Soft Reset
Performs a soft reset of the ServerNet switch board.
Service Processor (SP)
The service processor (SP) controls environmental and maintenance functions and acts as the master
of the serial maintenance bus (SMB). The service processor is a physical component of the processor
multifunction (
PMF ) customer-replaceable unit (CRU) and the I/O multifunction ( IOMF ) CRU.
Location in OSM Tree: System > Group > Module > PMF2 > SP
Slot Location: Service processors are located on the PMF CRUs and IOMF CRUs in slots 50 and 55
of processor and I/O enclosures (service side).
Example: SP (1.1.50)
Attributes
SP
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Values
Physical
Time Of Last Reset The date and time that the service processor was last reset.
Stored Topology
The maximum processor configuration for the service processor that is set
the next time the system or enclosure is powered on.
Values
Master SP
Whether this service processor is the master service processor on the
system:
True: This is the master service processor.
False: This is not the master service processor.
Running Image Source
Whether the SP firmware was loaded from its own, the peer's, or the backup
flash memory.
Values: ???, Running From Local Flash
