Running the Export Tool
To run the Export Tool and save monitoring data in files, you need to execute your batch file. To execute
your batch file, you need to enter the name of the batch file at the command prompt and then press the
key (see Figure 42 on page 93 for reference). If you are using a Windows computer, you can
double-click the batch file to execute the batch file.
c:\WINDOWS> cd c:\export ⇦ Go to the directory containing runWin.bat
c:\export> runWin.bat ⇦ Execute runWin.bat
Figure 42 An Example of Executing a Batch File (on a Windows Computer)
When the Export Tool starts exporting monitoring data, dots (...) are issued to the standard output
(for example, the command prompt). The dots increment as export processing continues (see
Figure 43 on page 93). If an internal error occurs, the exclamation mark (!) is issued to the standard
output and the Export Tool attempts to restart exporting data. If the export processing restarts, dots
reappear and increment until export processing finishes.
[ 2] svpip 158.214.135.57 ⇦ Displays the currently-running subcommand
[ 3] login User = expusr, Passwd = [****************] ⇦ Displays the currently-running subcommand
:
:
[ 6] group Port ⇦ Displays the currently-running subcommand
:
:
[20] apply ⇦ Displays the currently-running subcommand
Start gathering port data ⇦ Indicates that the export processing starts
Target = 16, Total = 16
+----+----+----+----+----+----+----+----+----+----+
...........................! ⇦ Indicates that an error occurs during the export processing
................................. ⇦ Dots appear and increment as the export processing continues
End gathering port data ⇦ Indicates that the export processing ends successfully
Figure 43 An Example of Command Prompt Outputs When the Export Tool Runs
When the Export Tool finishes successfully, monitoring data are usually compressed in ZIP-format archive
files. To obtain CSV files, you need to decompress ZIP files and extract CSV files out of the ZIP files.
If the operating system on your computer does not include a feature for decompressing ZIP files, you
need to obtain software for decompressing files.
For a complete list of files to be saved by the Export Tool, see “
Files to be Exported ” on page 73.
Notes:
• When an internal error occurs during export processing, the exclamation mark (!) appears and
then retries export processing. Usually the Export Tool can retry processing up to three times.
If export processing does not finish through three retries or if an internal error occurs other than
those in Table 27 on page 94, the Export Tool does not retry the processing. In this case, you
need to quit the command prompt and then run the Export Tool again.
Note that you can change the maximum number of retries by using the retry subcommand. For
detailed information about the retry subcommand, see “ retry Subcommand ” on page 99.
XP24000 Performance Monitor User's Guide 93
