ZIP File CSV File Data Saved in the File
RCLDEV_Remained_Record­
set.ZIP
RCLDEV_Remained_Record­
set_xx.csv
The number of remaining recordsets
when the schedule is completed
RCLDEV_Scheduling_At­
tempt.ZIP
RCLDEV_Scheduling_At­
tempt_xx.csv
The number of job activations of
consistency manager
RCLDEV_Pair_Synchro­
nized.ZIP
RCLDEV_Pair_Synchro­
nized_xx.csv
The percentage of completion of
copy operations (that is, number of
synchronized pairs / total number of
pairs)
RCLDEV_Out_of_Tracks.ZIP RCLDEV_Out_of_Tracks_xx.csv
The number of tracks that have not
yet been copied by the initial copy or
resync copy operation
* 1 millisecond is one-thousandth of 1 second.
Note: The letters xx in CSV filenames indicate a CU image number. For example, if the filename is
RCLDEV_All_RIO_10.csv, the file contains the total number of remote I/Os of the volumes controlled by
the CU whose image number is 10.
Table 22 Files with Statistics about Remote Copy Operations by Continuous Access
and TrueCopy for Mainframe (At CLPR)
ZIP File CSV File Data Saved in the File
RCCLPR_dat.ZIP RCCLPR_SideFile.csv Sidefile usage rate per CLPR (The unit is %)
Table 23 Files with Statistics about Remote Copy Operations by Continuous Access
Journal and Universal Replicator for Mainframe (In the Whole Storage System)
ZIP File CSV File Data Saved in the File
UniversalReplicator.ZIP UniversalReplicator.csv
The following data in the whole storage system are
saved:
• The number of write I/Os per second
• The amount of data that are written per second
(The unit is KB/sec)
• The initial copy hit rate (The unit is percent)
• The average transfer rate for initial copy
operations (The unit is KB/sec)
• The number of asynchronous remote I/Os per
second at the primary storage system
• The number of journals at the primary storage
system
• The average transfer rate for journals in the
primary storage system (The unit is KB/sec)
• The remote I/O average response time on the
primary storage system (The unit is millisecond*)
• The number of asynchronous remote I/Os per
second at the secondary storage system
• The number of journals at the secondary storage
system
• The average transfer rate for journals in the
secondary storage system (The unit is KB/sec)
• The remote I/O average response time on the
secondary storage system (The unit is millisecond*)
* 1 millisecond is one-thousandth of 1 second.
XP24000 Performance Monitor User's Guide 85
