Continuous Access XP Journal user guide 91
• Mirror ID: Mirror ID. This column is blank if the journal group’s attribute is neither Master nor
Restore.
• S/N: Remote disk array’s serial number. This column is blank if the journal group’s attribute is
neither Master nor Restore.
• Pair JNLG: Number of a journal group in the remote disk array. This column is blank if the journal
group’s attribute is neither Master nor Restore.
• Controller ID: Remote disk array’s controller ID (that is, disk array family ID). This column is blank if
the journal group’s attribute is neither Master nor Restore.
NOTE: The controller ID for an XP10000/XP12000 disk array is 4.
• Path Gr. ID: Path group IDs, which are used to identify path groups (that is, groups of logical paths).
Up to eight logical paths can be registered in one path group. This column is blank if the journal
group’s attribute is neither Master nor Restore.
• CLPR: Journal group’s CLPR number.
• CTG: Number of a consistency group to which the mirror belongs. This column is blank if the journal
group does not have any volume pair.
• Preset: Detailed information about operations that will occur when you click Apply.
• List: Displays changes made in the pane. When you change settings in the pane, the changes are
displayed in the Preset list before the changes are applied to the disk arrays. If you are sure that
information in the Preset is correct, click Apply to apply the settings.
NOTE: When the Preset list displays changes made, you can only perform the same type of
operation that you have been doing, and cannot perform most other operations. You can only view
detailed information about journal groups even when the Preset list displays changes. For example,
if you are trying to delete journal groups and the Preset list displays the journal groups you want to
delete, you cannot perform other operations, such as splitting or restoring mirrors.
HaltAccept An operation for splitting the mirror has been started. The status of the journal group
immediately changes to Halting.
NOTE: HaltAccept can indicate the status of restore journal groups, but cannot indicate the
status of master journal groups.
Halting An operation for splitting or deleting the mirror is in progress. The primary and secondary
volumes are not synchronized.
When you split a mirror, the status changes in the following order: Halting, Halt, Stopping,
and finally Stop.
When you delete a mirror, the status changes in the following order: Halting, Halt, Stopping,
Stop, and finally Initial.
Halt An operation for splitting or deleting the mirror is in progress. The primary and secondary
volumes are not synchronized.
Stopping An operation for splitting or deleting the mirror is in progress. The primary and secondary
volumes are not synchronized.
Stop Either of the following:
• The operation for splitting the mirror is finished.
• The operation for deleting the mirror is in progress.
The primary and secondary volumes are not synchronized.
Blank No data volumes are registered in this journal group.
