HP StorageWorks XP Remote Web Console Software - Manual (Page 100)

100 Continuous Access XP Journal
NOTE: If an error occurs, the right-most column of the Preset list displays the error code. To view detailed
information about the error, right-click the error code, and select Error Detail. An error message appears
providing detailed information about the error.
Figure 47 Change JNL Option pane
The Change JNL Option pane displays the following:
• Meta/Data Ratio: Specify the ratio of metadata area to journal data area. For example, if you select
16, the ratio of metadata area to journal data area is 1:16. If you select 32, the ratio of metadata area
to journal data area is 1:32.
NOTE: Currently, you cannot change the ratio of metadata area to journal data area.
• Extent: Specify the number of extents.
NOTE: Currently, the number of extents is always 32 and cannot be changed.
• Inflow Control: Specify whether inflow of update I/Os to the journal volume is restricted (in other
words, whether to slow delay response to hosts).
• Yes: Inflow is restricted.
• No: Inflow is not restricted.
NOTE: If you select Yes and the metadata or journal data is full, update I/Os might stop.
• Data Overflow Watch (0 to 600 sec): Time (in seconds) for monitoring whether metadata and journal
data are full. This value must be within the range of 0 to 600 seconds.
NOTE: Currently, the value of Data Overflow Watch is predefined and cannot be changed. If
Inflow Control is No, Data Overflow Watch does not take effect and does not display anything.
• Copy Pace: Pace (speed) for an initial copy activity for one volume. The default is Low.
• Low: Speed of initial copy activity is slower than Medium and High.
