Continuous Access XP Journal user guide 113
• To modify a setting, select and right-click the setting, and select Modify.
• To cancel a setting, select and right-click the setting, and select Cancel.
14. Click Apply to start the pair creation and initial copy operations.
NOTE: If an error occurs, the right-most column of the Preset list displays the error code. To view
detailed information about the error, right-click the error code, and select Error Detail. An error
message appears providing detailed information about the error.
15. In the list of the Pair Operations pane, verify that the status of the pair is COPY. To monitor the progress
of the paircreate operations, click Refresh to update the information in the list or use the Pairdisplay
pane to monitor the detailed status of each pair.
Figure 53 Paircreate pane
The Paircreate pane displays the following:
• P-VOL: Primary data volume. The numbers indicate the primary data volume’s port number, host group
number, and LUN. The numbers in parentheses are the CU and LDEV numbers.
NOTE:
• P-VOL displays only one primary data volume even when two or more primary data volumes are
selected in the Pair Operation pane. P-VOL only displays the primary data volume that has the
smallest LUN (LU number).
• If a logical volume is an external volume, # appears after the LDEV number. For more
information about external volumes, see the HP StorageWorks External Storage XP User Guide.
• S-VOL: Select a secondary data volume. When specifying a secondary data volume, use the
drop-down lists to select the secondary data volume’s port, host group, and LUN.
