9.WAVEFORM DISPLAY

72

9-2. Graph Plotting

9-2-1. Continuous

Graph plotting is started by turning on the START/STOP key or turning on the ST/SP

external input. When it ends on one screen, the screen is cleared after expiration of the

interval time and graph plotting restarts on the next screen. It is ended by turning off the

START/STOP key or turning off the ST/SP external input.

t

START/STOP

ST/SP

Start

Plotting Period

Screen Hold

Plotting Period

X end point

X end point

Screen Clear

Interval Time

Key

Outside Input

time setteing

time setteing
