19.SELF-CHECK AND INITIALIZATION

108

19-1-3.

Self-Check KEY

The touch panel keys are checked.

How to set

19-1-4.

Self-Check EXT

The external I/O is checked.

How to set

Black-bordered pseudo keys appear on the blue screen. These keys should change

to white when pressed.

When all keys are pressed, the original screen is restored. If the color does not

change with no reaction due to a problem, it is NG.

In the case of NG, the original screen is restored in 30 seconds after the last key

operation.

Setting call

Page 1

System

Pseudo LEDs for the input terminals and pseudo ON/OFF keys for the output

terminals appear.

When each input terminal is shorted (turned on), the pseudo LED lights.

When each output terminal key is pressed, the output is turned on.

The original screen is restored by the ESC key.

Setting call

Page 1

System
