24.SPECIFICATIONS

114

24. SPECIFICATIONS

24-1. Analog Section

Sensor excitation

10V, 5V, 2.5V DC (digital adjustment)
Output current: Within 120mA
4-wire (Up to four 350

load cells can be connected.)

Signal input range

-3.0 - +3.0mV/V

Zero and gain adjustment

Performed by digital computation

Accuracy

Non-linearity

Within 0.02%FS ± 1 digit (at a 3.0mV/V

input)

Zero drift

Within 0.5

V/

RTI

Gain drift

Within 0.01%/

A/D converter

Rate

2000 times/sec.

Resolution

16 bits (binary)

Analog filter

10Hz, 30Hz, 100Hz, 300Hz (digital adjustment)

Analog voltage output

Output level

Approx. 2V per 1mV/V of input Load

resistance

2K

or more

24-2. Digital Section

Display

STN color LCD module (display area: 75mm × 56mm)

320 × 240 dots

Indicated value: ± 99999 (5-digit)

Equivalent input calibration

Range: 0.5 - 3.0mV/V

Error: Within ± 0.1%FS

Hold functions

1) Sample hold

2) Peak hold

3) Valley hold

4) Peak-to-peak hold

5) Relative maximum hold

6) Relative minimum hold

7) Inflection point hold

Period setting (all period, external signal, time, time with

trigger) is available for 2) - 4).

Combinations allow selection from 16 hold types.
