24.SPECIFICATIONS

117

24-6. General

Required power source

- AC spec :100V to 240V AC (

10%

15%)

[free power source 50/60Hz]

- DC spec :12V to 24V DC ( ± 15%)

(Depending on the request at the time of order)

Power consumption

- AC spec: 15W (30VA) max.

- DC spec: 20W max.

Rush current (Typ)

15A, 5 msec.: 100V AC mean load state

(ordinary temperature, at cold-start time)

30A, 5 msec.: 200V AC mean load state

(ordinary temperature, at cold-start time)

Operating conditions

Temperature

-10

to +40

Humidity

80%RH or below (non-condensing)

Warmup time

20 minutes

Dimensions

100W × 96H × 135D

mm (excluding projected parts)

Weight

About 1kg
