1.APPEARANCE DESCRIPTION
2
1-2. Rear Panel
Terminal block
Signal input / output connect
Frame ground
Signal I/O terminal
Optional slot
AC power source
input terminal block
block
1
GND
2
VOL OUT
3
+SIG
4
-EXC
5
-SIG
6
+EXC
over
under
1
2
3
4
5
6
terminal block
terminal block
fix screw
fix screw
A1
COM1
B1
COM2
A2
OUT
HH
B2
IN
CODE0
A3
OUT
HI
B3
IN
CODE1
A4
OUT
OK
B4
IN
CODE2
A5
OUT
LO
B5
IN
CODE3
A6
OUT
LL
B6
IN
T/H
A7
COM1
B7
COM2
A8
OUT
H/E
B8
IN
H/M
A9
IN
D/LOCK
B9
IN
D/Z
A10
OUT
EVENT
B10
IN
ST/SP
A11
OUT
SI/F
B11
IN
CAL0
A12
OUT
SI/F
B12
IN
CAL1
A1
B1
A12 B12
