14.BCD DATA OUTPUT(OPTION)

92

14. BCD DATA OUTPUT(OPTION)

The BCD data output is an interface to extract the indicated value of the F371 as BCD

data. This interface is convenient to process controls, totals, records, etc., by connecting

the F371 to a computer, process controller, sequencer or the like.

The I/O and internal circuits are electrically insulated by photocoupler.

The data output rate can be selected from once/sec., 10 times/sec., 100 times/sec., and

1000 times/sec.

14-1. Connector Pin Assignment

Anphenol Connector

36-Pin

Compatible connector is DDK57-30360 or equivalent.

No.

Signal

No.

Signal

1

COM

19

COM

2

Out

1

20

Out

20000

3

Out

2

21

Out

40000

4

Out

4

22

Out

80000

5

Out

8

23

Out

Minus(Palarity)

6

Out

10

24

Out

OVER

7

Out

20

25

Out

P.C

Stable

8

Out

40

26

Out

STROBE

9

Out

80

27

In

BCD Data Hold

10

Out

100

28

In

Logic Switching

11

Out

200

29

12

Out

400

30

13

Out

800

31

14

Out

1000

32

15

Out

2000

33

16

Out

4000

34

17

Out

8000

35

18

Out

10000

36
