25.SETTING ITEM CHART
122
Setting of Option
Setting of Option
Setting of SYSTEM
In case of used Output Mode
page
Item
Default
Calibration
LOCK
Set Value
LOCK
N
S
1
Output Mode
Input Value
2
Voltage Zero Output
00000
3
Voltage Full Scale
10000
4
Current Zero Output
00000
5
Current Full Scale
10000
6
2
Voltage Output Selection
Hold Value
7
Current Output Selection
Hold Value
In case of used RS-485
page
Item
Default
Calibration
LOCK
Set Value
LOCK
N
S
1
Comm.Mode
MODE0
2
Speed
9600bps
3
Character Length
8bit
4
Stop
1bit
5
Parity
No
6
Terminator
CR
7
ID
0000
8
end.reg
No
9
wire-sel
4wire
page
Item
Default
Calibration
LOCK
Set Value
LOCK
CH
Note
1
All Para.Clear
2
Self Check DSP
3
Self Check MEM
4
Self Check KEY
5
Self Check EXT
6
2
PASSWORD
7
LANGUAGE
ENG
